As a reliable and proven base of testing our mechanisms, systems and ideas, we produce a quadcopter with a frame size of 1000mm.

The frame is made of composite materials and has a significant margin of rigidity and reliability to ensure good flight parameters for flight with different loads and systems. The frame is of one piece construction and is manufactured in one piece with beams and mounts for all necessary components.

Such a frame is positioned as a platform for your projects. You can equip it with the payloads you require, a modified propulsion system or unique flight algorithms and sensors.

The photo shows a side view of the prototype. The drone has high landing legs for easy placement of equipment. As an example, the three-axis gimbal mount for a camera with a zoom lens is shown.

Below are the main flight and technical characteristics of the quadcopter. You can contact us for specific parameters.

Parameter	Value
Size	1000mm x 1000mm
Propeller	17 inch
Mass with battery	3.5 kg
Battery capacity	24 V 9 Ah
Flight time (no payload)	25 min
Max payload for take off	4 kg

The video shows a short segment of the copter flight.

The proposed solution can be the basis for making a quadcopter for various applications. By varying the payload it is possible to scan the terrain, use the drone for aerial photography or other missions requiring a high payload and flight time.

The payload of the drone can be used to install an additional battery, which can increase the flight time of the drone up to 45 minutes.
